The gap between rotor and machine case can be adjusted .There is the wide -door or full opened door at the bottom ,no residual.Both the
ends of machines are designed double -deck,avoid to leakage materials ;The discharge outlet is controlled by pneumatic (also dynamic electric or manual),
making the action more accuracy and sealing function much better.The oil pipe is installed inside the machine .
The whole structure is reasonable ,nice appearance .It is convenient for operation and maintenance.
1.The degree of homogeneity is high CV<5-7%
2.Mixing time :3-6minutes
3.Discharge structure :manual ,electric or pneumatic . 4.It is applicable to industries such as energy environment protection ,chemical ,feed food and medicine plants ,and organic
|
Model |
M3/Batch |
Power (KW) |
CV<% |
Time (m) |
Weight (T) |
Dimension (mm) |
|
TCDZ100 |
0.20 |
3 |
|
|
0.35 |
1400*590*750 |
|
TCDZ250 |
0.50 |
5.5 |
|
|
0.75 |
1860*805*900 |
|
TCDZ500 |
1 |
7.5 |
|
|
1.2 |
2100*1050*1200 |
|
TCDZ1000 |
2 |
18.5 |
|
|
2.1 |
2500*1630*1800 |
|
TCDZ2000 |
4 |
22 |
|
|
3.5 |
2800*1800*2600 |
|
TCDZ3000 |
6 |
30 |
|
|
4.2 |
3200*1900*2100 |
|
TCDZ5000 |
10 |
37 |
|
|
6.3 |
4600*2100*2300 |
