1、Vertical die,feeding vertically,no arching of raw material,easy for heating
dissipation.
2、Die fixed and vertical installation,the machine fised easily,working smooth and steady.
3、Rollers rotating,material centrifugal,evenly distributed around.
4、Double-layers die,up and down dual use,high capacity and saving energy.
5、Lubricating oil return system between transmission parts and bearing body.Oil circulation cooling,automatic timing to the oil lubrication to ensure adequate bearing lubrication, reducing oil consumption, more secure and reliable.
6、Directly transmission with high-precision,evolvent cylinder,helical tooth gear,transmission efficiency more than 98%.
7、Transmission gear and gear billet through normalzing high heat treatment,enhance hardness of the tooth surface.Tooth surface adopt carburize technology,carburized layer reach 2.4mm,increase the abrasive resistance,increase life time.Tooth surface handle through accurate grinding,slient,tip relief,make it operates with quiet and steady.
8、Principal axis and connection hollow shaft both adopt German alloy steel,through water hammer,rough turn heat treatment,finish turning.
9、The bear and oil seal for transmission part all adopt Japan high precision bear and America wear resisting.Heat-resistant fluoro rubber oil seal.
10、Pellet molding system adopt high quality silent bear and add thin oil circulation cooling lubrication system.The life time will be increase and operated more safely.

Type Model	Main Power（kw）	dimension （mm）	weight（kg）	Capacity （kg/h）	number of roller（Piece）	Diameter of forming holes（mm）	Die discharge hole Rows（layer）
TCZL-45H	45	2100*1000*1550	2700	600-800	2	6-10	4
TCZL-55H	55	2200*1000*1650	3000	800-1000	2	6-10	4
TCZL-560	90	2630x1300x2300	6100	1000-1500	2	6-12	4
TCZL690	132	2650*1500*2500	5000	1500-2000	2	6-14	4
